Grasshopper – Parametric Bridge

The objective of this tutorial is to acquire fundamental knowledge of Grasshopper through a simple definition that employs various functions and components. The intention is to construct an entire bridge starting from a single point, which will be converted into lines, surfaces, volumes, and ultimately, a bridge. Since all the stages are parametric, it allows for endless possibilities to generate countless variations.

Bridge Length

Let’s start with a point set in {0,0,0}

The bridge will need 3 points, one to start, one to end, this will be the length of the bridge, and in between a point to design the curvature of the bridge. This point will be on the line drawn by the two others and will be able to move along the line and in height.

Now let’s create the point on the line

Add a Point on Curve

We have our 3 points.

Bridge height

The middle one will be raised create the arch. Then, a curve is created linking first, raised midpoint and last

Bridge width

The curve is copied horizontally to obtain the bridge width. This is done by moving the curve Y direction.

Add a Loft to create the bridge deck, Nota, the Relay is put to have a better presentation, create a Relay by double clicking on the Wire.

The bridge can have a thickness by extruding the loft surface.


Let’s first create the vertical bars that hold the handrail

Finish by transforming lines into solid objects. Here, extruded polygons are used, this is one solution among many. For the handrail, it’s also possible to use a Tube which is easier…but creates more polygons.


Whole definition

The bridge at its first definition is done


Kindly complete this form to provide feedback on this exercise.

Thank you

to Follow…inserting Parametric Bridge Into Unity.

Light Simulation RGB additive with IES


In this tutorial, the idea is to verify if render software properly simulate colour mixing. For that, we will use, when possible, IES files in order to mimic as much as possible real phenomena. It extends and refreshes the previous tutorial on the same topic:

Colour mixing refers to Grassmann’s laws ( In colorimetry, Grassmann’s laws govern the superposition of colours. They serve as the foundation for all colorimetric calculations. Hermann Grassmann’s 19th-century studies of human colour perception led him to formulate three laws in his 1853 article « On the Theory of Colour Mixing. » (Grassmann, H. (1853). « Zur Theorie der Farbenmischung »). Continuer la lecture de Light Simulation RGB additive with IES

Grasshopper, Urban Analysis, 2D Isovist

In this tutorial, the idea is to explore the potential of Isovist for urban analysis. Isovist is the surface or volume of space visible from a specific point. This concept has been proposed by Clifford Tandy in 1967 and then redefined by Michael Benedikt. Isovists are very useful to quantify the perception of urban spaces such as opening, closeness, and also useful to define urban envelopes. Isovists help to with non-intuitive solutions for complex problems.

In this example, we will see how to set up an environment, then use a simple Isovist System, then a more complex one with Ladybug. Then we will see a non-intuitive question: where a very high tower can be seen in a dense urban context.

Let’s dive. Continuer la lecture de Grasshopper, Urban Analysis, 2D Isovist
