Photogrammetry – reconstruction – 3Dpdf export
Set-up
The photogrammetry has been done with a very small setup. The Sony DSC QX10 has been used for its very small size which made the process easier.
Continuer la lecture de Photogrammetry – Vase – top down reconstruction →

Shooting / Prise de vue
47 photographs were taken (18mm, F/13) with the flash, at heights spanning from 10 cm to 1 m from the ground. The surrounding stabilisation boards were left, to help Photoscan rebuilding the geometry. The photo series was imported into Photoscan.
47 photographies ont été prises (18mm, focale F/13) au flash à des hauteurs variant de 10 cm à 1 mètre du sol. Les planches de stabilisation pourtourantes ont été laissées afin d’aider Photoscan à remonter la géométrie. La série de photos est importée dans Photoscan. Continuer la lecture de Photoscan-photogrammetry workflow. →
