Revue d’histoire maritime numéro 18


Publication de l’article “Avel” le numéro 18 de la Revue d’Histoire Maritime.

Description générale :

Revue d’histoire maritime numéro 18

Travail et travailleurs maritimes, XVIIIe – XXe siècle : du métier aux représentations

Le numéro 18 de la Revue d’histoire maritime se compose de deux groupes de contributions. Le dossier principal, qui donne son titre à ce numéro, comporte douze textes consacrés au travail et aux travailleurs maritimes du XVIIIe siècle à la fin du XXe.Il s‟agit d‟un champ scientifique à la confluence entre deux courants pionniers de la recherche en sciences humaines : l‟histoire du travail et l‟histoire maritime.

Il ne s‟agit pas, comme ce fut souvent le cas, d‟une simple histoire ouvrière, mais d‟aborder tous les aspects, dans le domaine maritime, de l‟histoire du travail et des travailleurs. Les navires en mer offrent à cet égard un domaine remarquable car il s‟agit d‟un secteur économique qui a notablement été touché par les révolutions industrielles successives, et qui a été marqué, dès la marine commerciale à voile, par la mondialisation. Les problèmes sociaux sont également abordés en profondeur aussi bien sous l‟angle du niveau de vie que sous celui des revendications sociales. Enfin, l‟image du marin et son évolution à l‟ère de la mécanisation et de l‟industrialisation se voit accorder une large place. Le deuxième dossier est constitué par la recherche en cours grâce à huit contributions d‟étudiants préparant leur doctorat en histoire, qui proposent des mises au point sur l‟état de leurs travaux. Le caractère très neuf de l‟ensemble frappe, tout comme la diversité des sujets, puisque l‟on va de la piraterie au XVIIe siècle aux conditions actuelles du travail en mer, en passant par le commerce du vin d‟Aquitaine avec la Bretagne au XVIIIe siècle ou par la place de l‟immigrant dans les stratégies de la Compagnie générale transatlantique de 1884 à 1924. Les deux articles de varia sont tout aussi neufs puisque l‟un traite des « représentations artistiques des rivages comme outils de connaissance de l‟évolution du littoral », en prenant des exemples bretons, et que l‟autre montre, à partir du relevé de bateaux classés monuments historiques, les étonnantes possibilités des archives virtuelles en ligne. Enfin, ce numéro comporte de nombreuses recensions d‟ouvrages.

20/07/2014
16 x 24, 350 p.
ISBN : 978-2-84050-942-4

http://pups.paris-sorbonne.fr/pages/aff_livre.php?Id=1093

LE ROCHER GRAVÉ DE LA VALLÉE AUX NOIRS


LE ROCHER GRAVÉ DE LA VALLÉE AUX NOIRS BUTHIERS

https://www.academia.edu/7501143/Le_Rocher_grave_de_la_Vallee_aux_Noirs_Buthiers_Seine-et-Marne_._Campagne_2013._109._Cassen_S._Grimaud_V._Lescop_L._Caldwell_D._2014._Art_rupestre_bulletin_du_Gersar_65_p._25-37

Résumé

Une campagne de levés numériques sur des représentations de haches emmanchées et lames polies néolithiques, menée en juin 2013entre les bassins de l’École et de l’Essonne dans le cadre du programme Jade 2 de l’ANR,a conduit à la découverte à Buthiers (Seine-et-Marne) d’un important panneau de gravures comprenant une hache à manche crossé, un motif anthropomorphe et deux motifs temporairement interprétés comme des embarcations sans équipage.Le support est composé d’un énorme bloc degrés stampien dégagé par l’érosion sur le bord d’une petite vallée sèche (Vallée aux Noirs) en rive droite de l’Essonne. La particularité du site est de présenter une accumulation sédimentaire au pied de la paroi recouvrant la base du manche de la hache et le pied de la composition anthropomorphe. Une série de levés photogrammétriques et photographiques sous éclairages tournants a permis une première acquisition générale des données,débouchant sur un modèle tridimensionnel du support et sur des relations chronographiques inter-signes que devrait compléter, voire corriger, la campagne 2014.

Article Antiquity

A discovery of exceptional Neolithic engravings in Buthiers, Seine-et-Marne, France

Serge Cassen, Laurent Lescop, Valentin Grimaud & Duncan Caldwell


http://journal.antiquity.ac.uk/projgall/cassen340

Introduction

Click to enlarge

Figure 1. Distribution of hafted axe engravings from the fifth and fourth millennia BC in north-western France (after Cassen 2012).

Figure 1. Distribution of hafted axe engravings from the fifth and fourth millennia BC in north-western France (after Cassen 2012).

A campaign to record engravings of Neolithic axes in the Massif de Fontainebleau, south of Paris, (Figure 1) in June 2013 led to the discovery of a large panel of engravings consisting of a hafted axe with a crook handle, an anthropomorph, and two motifs that we have provisionally interpreted as boats. The engravings, which one of us (SC) found during joint prospecting, are on a huge block of Stampian sandstone that broke off the table rock around a dry valley on the right bank of the Essonne. The large size of the frieze (4.5m long by 2.8m high), and the high quality and techniques of the imagery, which includes bas-relief and champlevé, make this composition a major element for understanding Neolithic iconography in France.

The hafted axe

The hafted axe motif occurs between a natural projection on the left, whose ridge has been softened by percussion, and the anthropomorph on the right (Figure 2). The proximal end of the axe handle is still buried in the soil. On the basis of the size of a similar axe at Closeau in Nanteau-sur-Essonne (Bénard 2011), the handle probably extends for another 0.4m into the ground, and the original soil surface was probably at least that far again below the handle.

Click to enlarge

Figure 2. Photograph of the hafted Bégude-type axe. The handle is still partly buried in the soil.

Figure 2. Photograph of the hafted Bégude-type axe. The handle is still partly buried in the soil.

The shape of the blade is so clear that it can be identified as a Bégude axe, which is the oldest form in the Western European typology table for polished axes made of Alpine rocks (Pétrequin et al. 2012). The representation of such a large version (0.61m) of an imported tool in such an unusual spatial and architectonic configuration makes us think that it can only be understood by integrating it into the study of socially valued axes from the Alps.

The anthropomorph

The central motif extends over three slopes of the rock face: the first, at the bottom, is sub-vertical for 0.7m and descends into the ground; the one above it is 0.5m high; and the top one, which continues until the summit, is slightly inclined towards the back, and consequently shows the most obvious signs of weathering (Figure 3). The state of preservation of the engravings logically follows this same gradient.

The anthropomorph’s waist occurs along a natural ridge parallel to the ground, making it difficult to differentiate the artificial line forming the waist from a fold in the rock. This deliberate use of a natural feature is not repeated in the upper composition, which includes a nose, eyes, a probable beard and 10 plume-like motifs which fan symmetrically upwards from the brows on either side of an axis through the centre of the figure. Observations of before-and-after relationships show that the engraving was basically created from top to bottom.

Click to enlarge

Figure 3. Photograph of the anthropomorph. Note the hafted axe on the left and U-shaped crescent on the right.

Figure 3. Photograph of the anthropomorph. Note the hafted axe on the left and U-shaped crescent on the right.

Click to enlarge

Figure 4. A frontal view of the rock with the engravings graphically outlined as they appear in a 3D textured model.

Figure 4. A frontal view of the rock with the engravings graphically outlined as they appear in a 3D textured model.

Obvious analogies between these ‘plumes’ and those of anthropomorphs on other vertical rocks (Le Closeau, Caldwell 2013) and stelae in the region (L’Ouche de Beauce in Maisse, Tarrête 2001; Rouville in Malesherbes, Devilliers 2005) suggest that they are linked. Although the anthropomorph’s face resembles those at Closeau, the ‘beard’ makes this figure unique. Furthermore, a quadrangular sign engraved on the chest is the oldest part of the motif. The lower part of the anthropomorph, which is still buried, was not reached during the initial survey (Figure 4).

‘Boat’ 1

The ‘Boat 1’ motif is formed by a continuous line that forms a deep crescent with a single symmetrical projection on each side. The ensemble, which partially follows natural folds in the rock, seems to have been tilted intentionally towards the anthropomorph, whose right side touches the motif’s left flank at two points and reflects its general curve. The sign is similar to known representations of symmetrical vessels with raised extremities.

‘Boat’ 2

The previous motif is accompanied by a larger, more asymmetrical crescent on the right: ‘Boat’ 2. Two signs have been added to its high ends: one at an angle to the left and another near the summit on the right, where it forms a beak-like hook. The ensemble is seated on a huge fold in the rock, which curves under the anthropomorph’s face and above the hafted axe like a wave (Figure 5). The guiding lines of the representation lead us provisionally to interpret the motif as a vessel whose angularity suggests that it was made of sewn planks and whose right-hand projection suggests a paddle.

Click to enlarge

Figure 5. Profile and frontal views of a 3D photogrammetric model of the rock with a graphic inscription of the signs upon the supporting rock face.

Figure 5. Profile and frontal views of a 3D photogrammetric model of the rock with a graphic inscription of the signs upon the supporting rock face.

Future directions

During 2014, investigation of the discovery will be developed in two ways. First, test pits will be dug in the sediment accumulated at the foot of the frieze to reveal the buried parts of the lines and to evaluate sedimentation. The possible preservation of stratigraphic units might provide us with elements for direct or indirect dating, notably by 14C and OSL. The second goal is to perform a more thorough photographic recording under turning light, following protocols perfected in Brittany, which will allow better surface and chronological analyses of each line, so that an error-free dynamic model can be created.

The discovery already raises several implications. First, it lends support to the possibility of recognising real objects like large Alpine axe blades in engravings (Cassen 2012). Such axes, which were often highly polished, have been found in both sacrificial and mortuary contexts (individual tombs under tumuli), but never in domestic ones. It is worth noting that the axe below the ‘plumed’ face 3.2km away at Closeau also has a Bégude blade while the closest engraving of a hafted axe, in the ‘Grotte de la Hache’, is a different, northern type (Altenstadt/Greenlaw). Both forms are also present elsewhere in the region (cf. JADE database), with the latter occurring in Pecq (Yvelines) and Lieusaint (Seine-et-Marne), while an imitation of a Bégude blade was found in a spacious and uncommon individual VSG/Cerny tomb in the same commune as the new stela, Buthiers (Samzun et al. 2012).

The clarity of the motifs also makes it possible to make good comparisons with those in the Armorican zone, which presents new possibilities for framing studies and interpretative debates. The ‘plumes’ are remarkably similar to the ‘spouts’ of the two most realistic sperm whales of the Carnac region (Kermaillard, Mané Lud). At the same time, the individual elements of the fan-shaped structures may be associated with similar designs on some phallic motifs in Brittany.

But beyond these polysemic arrangements, the set of structural correspondences between the zones suggests that they were strongly linked. These include the association of hafted axes with quadrangles and crescents on stelae in both regions, while the interpretation of crescents in Brittany as boats (Cassen 2007) seems to have been validated by the details of the Buthiers crescents. The idea that semiotic entities were shared to such a degree by various Neolithic societies during the fifth and fourth millennia BC, that an iconographic repertoire was faithfully repeated across a zone that now encompasses Burgundy and the upper Rhone, can now be reasonably supported by referring to the huge ‘natural stela’ in the Vallée aux Noirs.

Acknowledgements

This study was programmed in 2011 and carried out under the aegis of the Jade2 Project ‘Interprétations sociales des objets-signes en jades alpins dans l’Europe néolithique’ (ANR-12-BSH3-0005-01), managed by the MSHE Ledoux, Franche-Comté University, with the help of the University of Nantes, the École Nationale Supérieure d’Architecture de Nantes, D. Simonin (Nemours Museum), J. Tarrête and L. Valois (Gersar).

References

  • BÉNARD, A. 2011. La hache gravée du Closeau (Nanteau-sur-Essonne, Seine-et-Marne). Art Rupestre (Bulletin du GERSAR) 60: 14.
  • CALDWELL, D. 2013. Le Visage gravé du Closeau 12 et ses implications. Nanteau-sur-Essonne (Seine-et-Marne). Art Rupestre(Bulletin du GERSAR) 64: 37–46.
  • CASSEN, S. 2007. Le Mané Lud en images. Interprétation de signes gravés sur les parois d’une tombe à couloir néolithique (Locmariaquer, Morbihan). Gallia-Préhistoire 49: 197–258. http://dx.doi.org/10.3406/galip.2007.2455(link is external)
    – 2012. L’objet possédé, sa représentation: mise en contexte général avec stèles et gravures, in P. Pétrequin, S. Cassen, M. Errera, L. Klassen, A. Sheridan & A.M. Pétrequin (ed.) JADE. Grandes haches alpines du Néolithique européen. Ve et IVemillénaires av. J.-C.: 1310–53. Besançon: Presses Universitaires de Franche-Comté; Gray: Centre de Recherche Archéologique de la Vallée de l’Ain.
  • DEVILLIERS, C. 2005. La dalle gravée de Rouville à Malesherbes (Loiret). Revue archéologique du Loiret occasional papers 1: 5–7.
  • PÉTREQUIN, P., S. CASSEN, M. ERRERA, L. KLASSEN, A. SHERIDAN & A.M. PÉTREQUIN (ed.) 2012. JADE. Grandes haches alpines du Néolithique européen. Ve et IVe millénaires av. J.-C. Besançon: Presses Universitaires de Franche-Comté; Gray: Centre de Recherche Archéologique de la Vallée de l’Ain.
  • SAMZUN, A., P. PÉTREQUIN & E. GAUTIER. 2012. Une imitation de hache alpine type Bégude à Buthiers-Boulancourt (Seine-et-Marne) au début du Ve millénaire, in P.A. de Labriffe & E.E. Thirault (ed.) Produire des haches au Néolithique: de la matière première à l’abandon, Actes de la table ronde de Saint-Germain-en-Laye, 16 et 17 mars 2007, musée d’Archéologie nationale: 219–34. Paris: Société préhistorique francaise.
  • TARRÊTE, J. 2001. La dalle gravée du monument mégalithique de l’Ouche de Beauce à Maisse (Essonne), in C.-T. Le Roux (ed.)Du monde des chasseurs à celui des métallurgistes. Hommage scientifique à la mémoire de Jean L’Helgouac’h et mélanges offerts à Jacques Briard (Revue archéologique de l’Ouest supplement 9): 149–54. Rennes: Revue archéologique de l’Ouest.

Authors

  • Serge Cassen
    Laboratoire de recherches archéologiques (CNRS UMR6566), Université de Nantes, BP 81227, 44312 Nantes, France (Email:serge.cassen@univ-nantes.fr)
  • Laurent Lescop
    École nationale supérieure d’architecture (UMR6566), 6 Quai François Mitterrand, 44000 Nantes, France (Email:laurent.lescop@nantes.archi.fr)
  • Valentin Grimaud
    Laboratoire de recherches archéologiques et Ensan, Université de Nantes (UMR6566), 44312 Nantes, France (Email:valentin.grimaud@univ-nantes.fr)
  • Duncan Caldwell
    Marine and Paleobiological Research Institute, 18 rue Rambuteau, 75003 Paris, France (Email: caldwellnd@aol.com)
